Genuine Volkswagen OEM Retrofit Kit – Rear View Camera (Low) – Atlas / Teramont CA1

NEW VW ATLAS / TERAMONT – Rear Camera KIT with Guidance Line

Handle with integrated camera and controller. Visual representation of the rear of the vehicle in the navigation system by way of the integrated camera

Features:

• No additional screens necessary
• Auto switch to the rear view cam by choosing the rear gear

Compatible with :

• New ATLAS / TERAMONT


Compatible with Head Unit:

• Composition Media
• Discover Media
• Discover Media Plus

• 3Q0 035 846
• 3Q0 035 846 A

Not Compatible with Head Units:

• 5G0035820A
• 5G0035820
• 5G0035819A
• 5G0035819
• 5G0035812

Note:

• On request we can perform the installation for you in our workshop
• VAS / VCDS Coding after installation required

Wiring Diagram:

RED         –      +12V constant
YELLOW  –      reverse light signal
BLACK     –     GND

Video Signal:

(QUADLOCK connector head unit) – 8X0 035 447

PIN No. 6   – transparent wire
PIN No. 12 – black wire

Scope of delivery :

• VW Camera in Handle
• Plug&Play Cable
